The grape seed drying machine is a professional device designed to reduce the moisture content of grape seeds, improve storage stability, and increase their value for further processing. In industries like grape seed oil, grape seed powder, and plant extracts, air energy (heat pump) drying machines are currently the most recommended option.
Compared with traditional high-temperature hot air drying, air energy dryers operate at low temperatures, are energy-saving and stable, and are better suited for grape seeds that require high nutritional quality and careful preservation of their properties.


Why Air Energy Drying Is Better for Grape Seeds?
Grape seeds are rich in oils and active compounds like proanthocyanidins, making drying more demanding:
- High temperatures can cause oil oxidation.
- Uneven drying affects subsequent pressing and grinding.
- High energy consumption increases long-term operating costs.
Air energy (heat pump) drying has clear advantages for grape seeds:
- Low and controllable temperature (usually 40–50 °C) protects nutrients.
- Constant temperature and humidity prevent surface drying while the inside remains wet.
- Even drying without charring or clumping.
- Suitable for long, continuous operation.

Who Can Benefit from an Air Energy Grape Seed Dryer?
Air energy grape seed drying machines are mainly suitable for:
- Wineries and fruit wine processing plants (for by-product utilization)
- Grape seed oil processing companies
- Health product and plant extract factories
- Agricultural product deep-processing and export projects
- Long-term production users with high requirements for energy efficiency and product quality
Grape Seed Drying Process
In practice, grape seeds are usually dried using the following air energy (heat pump) process:
Separation and Cleaning
- Separate the seeds from the grape skins and wash them briefly to remove impurities.
Draining Pre-treatment
- Drain the seeds after washing to reduce surface moisture.
Even Loading
- Spread the seeds evenly on trays or mesh racks to avoid piling.
Low-Temperature Air Energy Drying
- Dry with circulating hot air at 40–50 °C, allowing moisture to evaporate evenly.
Cooling and Discharging
- Once the moisture content drops to about 8–12%, discharge and cool the seeds before storage or further processing.
Low-temperature air energy drying helps maintain the stability of grape seed oils and preserves active compounds.

Working Principle
The air energy grape seed drying machine uses a heat pump circulation system. The entire process involves no open flames and no direct high-temperature air, making the drying stable and fully controllable.
Technical parameters of Grape Seed Drying Machine
| Model | Dimensions(mm) | Drying crews | Quantity of drying material (times/kg) |
| SL-2 | 4000*1860*2500 | 2 | 300-600 |
| SL-4 | 6000*1860*2500 | 4 | 500-1000 |
| SL-6 | 7200*2300*2500 | 6 | 800-1500 |
| SL-8 | 8500*2300*2500 | 8 | 1000-2000 |
| SL-10 | 10000*2300*2500 | 10 | 1200-2500 |
| SL-12 | 8500*3300*2500 | 12 | 2500-4000 |
| SL-18 | 8500*5000*2500 | 18 | 4000-6500 |
| SL-24 | 12000*5000*2500 | 24 | 5000-8000 |
Core Advantages of the Air Energy Grape Seed Drying Machine
Low-temperature drying ensures stable quality
Energy-saving and efficient, suitable for long-term operation
Even drying without clumping or charring
Automatic temperature control, simple to operate
Meets food and health product raw material standards
Low maintenance and long service life, reducing downtime and repair costs






Deep Processing Options for Dried Grape Seeds
- Grape Seed Oil Pressing
- Grape Seed Powder Production
- Plant Extracts (e.g., OPC raw materials)
- Functional Feed or Agricultural Reuse
Why Choose Shuliy Air Energy Grape Seed Drying Machine?
- Mature heat pump drying technology ensures reliable performance.
- Multiple specifications available, with customizable drying room sizes.
- Suitable for various materials, including seeds, pomace, and peels.
- Compatible with cleaning, conveying, grinding, and pressing equipment for integrated processing.
- Export-ready design, with stable operation and durable structure.
Shuliy not only provides air energy drying machines but also focuses on complete grape seed drying and deep-processing solutions, optimizing feasibility and long-term operating costs.
